Product Description
Yamada Pumps NDP-5FPT Type, Model 851562 NDP-5 Series, Air Operated Double Diaphragm Pump, PTFE Diaphragm, PTFE Flat Check Valve / O-Rings, Polypropylene (PPG) Material, 3.4 GPM Max Flow, 1/4" NPT Fluid Port, 1/4" Female NPT (includes ball valve) Air Inlet, 3/8" Female NPT (includes silencer) Air Exhaust, Ryton® Air Motor, 5 Feet Max Suction Lift.
Specifications
- Actual Weight: 5
- Air Exhaust: 3/8" Female NPT (includes silencer)
- Air Inlet: 1/4" Female NPT (includes ball valve)
- Air Supply Pressure: 20 to 100 PSI (1.4 to 7 kgf/cm²)
- Diaphragm: PTFE
- Discharge Volume Per Cycle: 0.0085 gallons (35 cc)
- Fluid Port: 1/4" NPT
- Liquid Temperature: 180°F (82°C) Max
- Material: Polypropylene (PPG)
- Max Cycles Per Minute: 400
- Maximum Flow: 3.4 GPM
- Max Suction Lift: 5 Feet
- Model Number: 851562
- Model Series: NDP-5 Series
- Motor: Ryton Air Motor
- Valve / Seat / O-Ring: PTFE
