Product Description
Yamada Pumps NDP-15FPT Type, Model 851699 NDP-15 Series, Air Operated Double Diaphragm Pump, PTFE Diaphragm, PTFE / PTFE Flat Check Valve / O-Rings, Polypropylene Flat Valve (PPG) Material, 13.5 GPM Max Flow, 1/2" NPT Fluid Port, 1/4" Female NPT (includes ball valve) Air Inlet, 3/8" Female NPT (includes silencer) Air Exhaust, Ryton® Air Motor, 8 Feet Max Suction Lift.
Specifications
- Actual Weight: 12
- Air Exhaust: 3/8" Female NPT (includes silencer)
- Air Inlet: 1/4" Female NPT (includes ball valve)
- Air Supply Pressure: 20 to 100 PSI (1.4 to 7 kgf/cm²)
- Diaphragm: PTFE
- Discharge Volume Per Cycle: 0.034 gallons (128 cc)
- Fluid Port: 1/2" NPT
- Liquid Temperature: 180°F (82°C) Max
- Material: Polypropylene - Flat Valve (PPG)
- Max Cycles Per Minute: 400
- Maximum Flow: 13.5 GPM
- Max Suction Lift: 8 Feet
- Model Number: 851699
- Model Series: NDP-15 Models
- Motor: Ryton Air Motor
- Solids: 1/32" (1 mm)
- Type: 851699
- Valve / Seat / O-Ring: PTFE / PTFE
