Product Description
Specifications
- Inlet Connection Size - NW16
- Outlet Connection Size - NW16
- Connection Type - ISO Flange
- Finish - Stainless Steel
Features
- All stainless steel construction
- Integrated drain port
- Vacuum service down to 1x10-3 Torr
- Leak rate: 1x10-7 mbar L/S
- Temperature range -20°C to 150°C
- Fine bead blast finish
- Viton O-ring
Filter Options
1. Molecular Sieve
- Traps water vapor and other gases
- Rechargeable 13X Zeolite desiccant
- Integral 120 VAC or 240 VAC regeneration heater
- Reduce oil change-out
2. Metal Wool
- Trap hydrocarbons and large particulate
- Replaceable stainless steel or copper insert
- Reduce contamination
3. Chemical Adsorbents
- Trap chemicals and corrosives
- Chemical compatible adsorbents available (ie: activated carbon, alumina, SodaSorb, etc.)
- Reduce hazards
4. Fine Particulate
- Trap fine particulate
- Multiple media available (down to .2 micron at 99.99% efficiency)
- Reduce dust and particle ingestion
